24V 4000VA (3600W) Hybrid Inverters ■ Three in one：This is a multi-function inverter/charger that combines functions of an inverter, solar charger and battery charger to provide uninterrupted power supply with portable size. ■ LCD screen：Its comprehensive LCD display provides user-configurable and easily accessible key controls such as battery charging current, AC/solar charging priority and acceptable input voltage based on various applications. ■ ON/Off-grid inverters：The island grid inverter can operate autonomously after leaving the power grid. It corresponds to an independent small power grid. It mainly controls its own voltage and is a voltage source. It can transport ohmic capacitive and motor inductive loads, has fast response and anti-interference, high adaptability and practicality, and is the power supply product of first choice for emergency power supply in case of power failure and outdoor power supply.
  • 【All-in-one solar charge inverter】3600W Solar Inverter 24V DC to 110V/120V AC, built-in 120A MPPT charge controller,fit for 24V Lead-Acid (Seal, AGM,Gel, Flooded) and Lithium battery. The solar charge module adopts the latest optimized MPPT tracking technology, with an efficiency of up to 98%.
  • 【TECHNICAL SPECIFICATIONS】3600VA Hybrid Solar Inverter Max.PV Input Power: 4200W, Voltage range: 60-500Vdc, Max. PV Input VOC: 500V DC;charge current: 120A.Nominal Input Frequency: 60Hz; Output Power: 3600W, surge Capacity: 7200W.
  • 【MULTIPLE CHARGING MODES】Off Grid Solar Inverter have 4 charging modes are optional, i.e. Only Solar, Mains First , Solar First and Mains & Solar hybrid charging;and 3 output modes are available, i.e. Solar First, Mains First and SBU Priority, uninterrupted power supply to meet different application requirements. And compatible to mains voltage or generator power, Auto restart while AC is recovering
  • 【LCD & LED DISPLAY】LCD display design and 3 LED indicators for dynamic display of system data and operating status, Configurable battery charging current, AC/Solar Charger priority and Load Supply Priority via LCD setting.Support WIFI remote monitoring,available for IOS and Android, users can monitor the status of the PV system from the mobile phone or from the website anytime anywhere. (Not included)
  • 【WIDE RANGE OF USES】MPPT Inverter Charger Pure sine Wave 3600W for RV Camping Boat Home Emergency etc.. Can be accessed to a variety of household and office loads, including Oven, rice cooker, lamps, televisions, fans and other AC loads.you can enjoy the stable power from the sun and the utility grid to keep you powered under any circumstances.
  • 📘MODEL：ECO-3.6KW
    Phase：1-phase
    Maximum PV Input Power：4200W
    Rated Output Power：3600W/3600VA(3000/3150/3300)
    Maximum Solar Charging Current：120A
    📘GRID-TIE OPERATION
    PV INPUT(DC)
    Nominal DC Voltage/MaximumDC Voltage：360/500VDC
    Start-up Voltage/Initial Feeding Voltage：60VDC/90VDC
    MPPT Voltage Range：60~450VDC
    Maximum Input Current：1/18A
    GRID OUTPUT (AC）
    Nominal Output Voltage：120VAC(100/105/115V settable)
    Output Voltage Range：90-150VDC
    Nominal Output Current：30A
    Power Factor：>0.99
    EFFICIENCY
    Maximum Conversion Efficiency (DC/AC)：98%
    TWO LOAD OUTPUT POWER
    Full Load：3600W
    Maximum Main Load：3600W
    Maximum Second Load(battery mode)：1200W
    Maximum Load Cut Off Voltage：26VDC
    Maximum Load Return Voltage：27VDC

  • 📘OFF-GRID OPERATION
    AC INPUT
    AC Start-up Voltage/Auto Restart Voltage：110VAC/120VAC
    Acceptable Input Voltage Range：90~145AC±2%
    Frequency Range：49~51±1HZ
    Maximum AC Input Current：40A
    PV INPUT(DC)
    Nominal DC Voltage/Maximum DC Voltage：360/500VDC
    MPPT Voltage Range：60-450VDC
    Maximum Input Current：1/18A
    BATTERY MODE OUTPUT(AC)
    Nominal Output Voltage：120VAC(100/105/115V settable)
    Output Waveform：Pure sine wave
    Efficiency(DC to AC)： 94%
    BATTERY & CHARGER
    Nominal DC Voltage：24VDC
    Maximum Solar Charging Current：120A
    Maximum AC Charging Current：100A
    Maximum Solar+AC Charging Current：120A

  • 📘HYBRID OPERATION
    PV INPUT(DC)
    Nominal DC Voltage/Maximum DC Voltage：360/500VDC
    Start-up Voltage/Initial Feeding Voltage：90VDC/120VDC
    MPPT Voltage Range：60~450VDC
    Maximum Input Current：1/18A
    GRID OUTPUT(AC)
    Nominal Output Voltage：120VAC(100/105/115V settable)
    Output Voltage Range：60-450VDC
    Nominal Output Current：30A
    AC INPUT
    AC Start-up Voltage /Auto Restart Voltage：120-140VAC/180VAC
    Acceptable Input Voltage Range：90-280VAC or 170-280VAC
    Maximum AC Input Current：40A
    Maximum Charging Current：120A

  • GENERAL
    PHYSICAL
    Dimension,D*W*H(mm)：420*350*110
    Cartoon Dimension,D*W*H(mm)：500*415*180
    Net Weight(kgs)：8.8
    Gross Weight(kgs)：10
    INTERACE
    Communication Port：RS232/RS485/WIFI/GPRS/LITHIUM BATTERY
    ENVIRONMENT
    Humidity：5% to 95% Relative Humidity(Non~condensing)
    Operating Temperature：-10℃~50℃
    STANDARD
    Compliance Safety：CE
